High Speed Automatic Glue Mixing Machine Pjl-1000b For Gluing Mode Daheng Plunger Pump

Details Information

Product Description

Detail Information

Model NO.:

PJL-1000B

Packaging:

Cartons

Size:

1100mm×800 Mm×1600mm

N.W:

310kg

Glues Used:

Double Components PU Silicone Eposy Etc.

Ratio:

From 1:1 To 10:1

Flow Speed:

66g5s, Customizable

Pump:

Patent Double Cylinder Plunger Pump

Transport Package:

Wooden Carton Lined With Foaming PE

Specification:

CE & SGS

Trademark:

Daheng / OEM

Origin:

Guangzhou China

HS Code:

842489990

Supply Ability:

50PCS / Month

Automatic Grade:

Automatic

Gluing Mode:

Daheng Plunger Pump

Packaging Material:

Plastic Or Metal

Glue Type:

Ab Glue

Application:

Machinery & Hardware

Driven Type:

Electric

Customization:

Available | Customized Request

Highlight:

automatic glue mixing machine

automatic ab glue machine

high speed ab glue machine

Product Description

High Speed Automatic Glue Mixing Machine Pjl-1000b
Features & Benefits:
1. Sealing & Vacuum System
2. An automatic systerm of metering and mixing.
3. Self-refilling
4. Self-cleaning
5. Easy to change the flow speed, ratio on the touch screen.
6. Easy to operate, assembly and disassembly.
7. Our Patent double cylinder plunger pump; specially designed for high precision, wearability and long life time

Application:
PJL-1000 can be applied in electronical & electroniccs where glue dispensing, mixing is demanded for sealing, filling, gluing such as: power supply, driver, transformer, controller, motor, circuit, PVB board so on and so mass.

Glues Ratio	From 1:1 to 10:1, optional
Out-gluing Speed	1-25g/s(influenced by glues ratio)
Ratio Accuracy	±1%
Data Memory	20
Air Pressure Input	0.4MPa_0.8MPa
Glue Viscosity	50cps~6000cps
Mode	Manual / Automatic
Metering & Mixing	PLC/ Double-Cylinder Plunger Pump (DH Patent)
Out-gluing Quantity	Digit Display, manual set
Program Method	Teaching mode
Center Control	Touch Screen
Control System for Out-gluing	Such-back Double-liquid Valve
Mixing Method	Dynamic Mixing
Tank	Stainless Steel Tanks; A: 30L, customizable; B: 10L
Power Input	220V/50Hz/1200W
Size	1100mm×800 mm×1600mm
