2.You can adjust the glue ratio and out-put quantity based on needs.
3. Easy to program, disassembly and install.
4.The high precision of mixing helps to avoid possible glue waste.
5. Automatic cleaning system can be added into the device if needed.
6. Wide applications
| Model & Type | PG-200 Full Auto Gluing Machine Dispenser |
| Certificate | CE, SGS |
| Dimension | 1500x800x1500mm |
| N.W. | 260kg |
| XYZ Working Area | 480x480x30mm |
| Flow Speed | 0-66g/5s, or customized |
| Moving Speed | 0-300mm per second |
| Glue & Ratio | 1:1 to 20:1, Epoxy, Silicone, PU, UV |
| Repeatability | +/-0.02g |
| Accuracy | +/- 1% |
| Power | AC220V or AC 380V |
| Total Power Consume | 3kw - 5kw |
| Additional Functions | Heating, Vacuum, Self-refilling, Self-cleaning |
| Application | LED module, display, LED lights, power supply, driver, motor, sensor, and transformer and so on^ |
Video
|
|
2.You can adjust the glue ratio and out-put quantity based on needs.
3. Easy to program, disassembly and install.
4.The high precision of mixing helps to avoid possible glue waste.
5. Automatic cleaning system can be added into the device if needed.
6. Wide applications
| Model & Type | PG-200 Full Auto Gluing Machine Dispenser |
| Certificate | CE, SGS |
| Dimension | 1500x800x1500mm |
| N.W. | 260kg |
| XYZ Working Area | 480x480x30mm |
| Flow Speed | 0-66g/5s, or customized |
| Moving Speed | 0-300mm per second |
| Glue & Ratio | 1:1 to 20:1, Epoxy, Silicone, PU, UV |
| Repeatability | +/-0.02g |
| Accuracy | +/- 1% |
| Power | AC220V or AC 380V |
| Total Power Consume | 3kw - 5kw |
| Additional Functions | Heating, Vacuum, Self-refilling, Self-cleaning |
| Application | LED module, display, LED lights, power supply, driver, motor, sensor, and transformer and so on^ |
