Customized Request Option High Speed Automation Dispenser for 25L and 10L Containers
  • name
  • name
  • name
  • name
  • name
  • name

Customized Request Option High Speed Automation Dispenser for 25L and 10L Containers

Details Information
Product Description
Detail Information
Model NO.:
PG-700
Packaging:
Cartons
Xyz Working Area:
700 X 700 X 30mm
Size:
L1500xw1200xh1500mm
Weight:
260kg
Ratio:
From 1:1 To 10:1
Stiring Method:
Static Or Dynamic
Pump:
Daheng Patent Plunger Pump
Out-Gluing Rate:
5-66g/5s
Mixing Precision:
+/-1%
Container Volume:
A:25L B:10L
Name:
High Speed Automation Dispenser
Transport Package:
Quality
Specification:
CE
Trademark:
Daheng Or OEM
Origin:
Guangzhou China
HS Code:
8424899990
Supply Ability:
50PCS / Month
Automatic Grade:
Automatic
Gluing Mode:
Piston / Plunger Pump
Packaging Material:
LED Display
Glue Type:
Ab Glue
Application:
Machinery & Hardware
Driven Type:
Electric
Customization:
Available | Customized Request
Highlight:

electric glue potting machine

,

automatic glue potting machine

,

electric epoxy potting machine

Product Description
 high speed automation dispenser

High Speed Automation Dispenser


Features and Benefits:
1, A system of metering, mixing and potting.
2, Accurate metering and even mixing helps to avoid possible waste of glue.
3, Shot size and positioning keep consistent, fast.
4, Good universality makes PGB-700DR suitable for applications of LED, electric and others glue potting needed.
5, Easy to program and operate.
6, Tally function, non-standard mode, primer mode, level alert, filter mode, liquid display device, preventing backflow device and other functional device.

Application:
Industry: Capacitor, power supply, transformer, ignition coil, reverse sensor, circuit board, electronic ballast, other electronic products and LED products where glue potting demanded.
High Speed Automation Dispenser

Glue:
Epoxy, silica gel, AB glue, PU and other glue which need matching

Optional Function:
1, evacuation
2, heating
3, Geared pump & plunger piston pump are available; Customers can choose to needs.
4, Control-card will be chosen to be added in to program to needs.
Model & Type PG-700 Full Auto Gluing Machine Dispenser
Certificate CE, SGS
Dimension 1500x1200x1500mm
N.W. 260kg
XYZ Working Area 700x700x80mm
Flow Speed 0-66g/5s, or customized
Moving Speed 0-300mm per second
Glue & Ratio 1:1 to 20:1, Epoxy, Silicone, PU, UV
Repeatability +/-0.02g
Accuracy +/- 1%
Power AC220V or AC 380V
Total Power Consume 3kw - 5kw
Additional Function Heating, Vacuum, Self-refilling, Self-cleaning
Application LED module, display, LED lights, power supply, driver, motor, sensor, and transformer and so on^
