Customize Your Order 480X480X30mm LED Display Automatic Glue Dispenser with Epoxy Glue
Products

Glue Potting Machine

Glue Dispensing Machine

Glue Mixing Machine

Meter Mix Dispensing Machine

Vacuum Potting Casting Machine

CCD Vision Dispensing System

Glue Dispenser

Spraying Glue Machine

High Precision Dispensing Valve

Epoxy Doming Machine

PU Dispensing Machine
Contact Us
Ms. Tina Peng
dh04@dahengkongjiao.com
86--18926136909
wechat 8613302264665
Contact Now
Customize Your Order 480X480X30mm LED Display Automatic Glue Dispenser with Epoxy Glue
  • name
  • name
  • name
  • name
  • name
  • name

Customize Your Order 480X480X30mm LED Display Automatic Glue Dispenser with Epoxy Glue

Details Information
Product Description
Detail Information
Model NO.:
PG-200
Packaging:
Cartons
Xyz Working Area:
480X480X30mm
Size:
L1000xw800xh1500mm
N.W.:
180kg
Ratio:
From 1:1 To 10:1
Stiring Method:
Static Or Dynamic
Out-Gluing Rate:
5-66g/5s
Mixing Precision:
+/-1%
Container Volume:
A:25L B:10L
Transport Package:
Carton Box Lined With Foaming PC
Specification:
CE
Trademark:
Daheng Or OEM
Origin:
Guangzhou China
HS Code:
8424899990
Supply Ability:
50PCS / Month
Automatic Grade:
Automatic
Gluing Mode:
Plunger Pump
Packaging Material:
Plastic
Glue Type:
Epoxy, Silicone, PU & Other Double Components
Application:
Machinery & Hardware, Commodity
Driven Type:
Electric
Customization:
Available | Customized Request
Highlight:

epoxy glue dispenser

,

epoxy glue dispensing equipment

,

pu glue dispenser

Product Description
Automatic Glue Dispenser for LED Display
Automatic Glue Dispenser for LED Display 480X480X30mm


I. Tech Data
Glue Ratio: From 1: 1 to 10: 1
Stirring mode: Static(standard)/dynamic(optional)
XYZ working area: 480*480*30mm
Data Memory: 20
Program Method: Teach & show-how method
Size: 1100 x 800 x 1500mm
Input Air: 0.5~0.7 MPa
Power Input: AC220V
Automatic Glue Dispenser for LED Display 480X480X30mm


II. Main Characters
1. It is an automatic system of simultaneous glue metering, mixing and dispensing.
2. You can adjust the glue ratio and out-put quantity based on needs.
3. The high precision of mixing helps to avoid possible glue waste.
4. Easy to program, disassembly and install.
5. Automatic cleaning system can be added into the device if needed.
6. Wide applications
Model & Type PG-200 Automatic Glue Dispenser for LED display
Certificate CE, SGS
Dimension 1500x800x1500mm
N.W. 260kg
XYZ Working Area 480x480x30mm
Flow Speed 0-66g/5s, or customized
Moving Speed 0-300mm per second
Glue & Ratio 1:1 to 20:1, Epoxy, Silicone, PU, UV
Repeatability +/-0.02g
Accuracy +/- 1%
Power AC220V or AC 380V
Total Power Consume 3kw - 5kw
Additional Functions Heating, Vacuum, Self-refilling, Self-cleaning
Application LED module, display, LED lights, power supply, driver, motor, sensor, and transformer and so on^
