High precision Panasonic PLC ensure high stably performance and precisely AB glue output quantity
|
| Price: | $12,000.00/sets |
| Standard Packaging: | wooden box packing for sea shipment |
Specification Epoxy PU silicone two parts glue manual dispensing machine | ||||||
Mixing Method: | Dynamic or Static, optional; | |||||
Repeatability: | ±1% | |||||
Mixing Accuracy: | ±1% | |||||
Tank Capacity: | 10L/25L/40L/60L or Customized | |||||
Mixing Ratio: | 1:1 - 1:10 adjustable | |||||
Gluing Speed: | 5-66g/5s adjustable; | |||||
Air Pressure: | 0.5-0.7Mpa | |||||
Power Input: | AC220V 50-60Hz or Customized | |||||
Dimension: | 1500*1200*1500mm | |||||
Weight: | 260KGS | |||||
Different types of stickers , badge , keychains , souvenirs ,arts , photo frame , and other arts graphics....
PGB-700 system accurately meters, mixes and dispenses two-component medium to low-viscosity materials for potting, gasketing, sealing, encapsulation and syringe filling. For variable ratio dispensing, the system handles ratios from 1:1 to 10:1.
The system is composed of material tank, metering pump, metering motor, material pipe, two component valve, motor for dynamic stirring and mixing tube. Two kinds of glue are separated before they mix in mixing tube, so the glue will not cure in devices. Glue valve is with vacuum function to keep thin fluid from dripping. Other optional functions include:
Tank stirring function; Tank defoaming function; Thermostat heating function on Tank, pipe, and pump;
Improved Product Quality: AB potting machines ensure accurate mixing and dispensing of
two-component adhesives, resulting in consistent product quality and reduced waste.
Increased Efficiency: These machines streamline the production process by automating the mixing and dispensing of adhesives, reducing the time and labor required for manual operations.
Customizable: AB potting machines can be customized to meet specific production requirements and adhesive types, providing
flexibility and versatility in the production process.
User-Friendly: These machines are designed for easy operation and maintenance, with user-friendly interfaces and accessible components that require minimal technical knowledge.
Cost-Effective: By reducing waste and improving efficiency, AB potting machines can provide significant cost savings over manual operations in the long run.
Safer Work Environment: Automated dispensing of adhesives reduces the risk of operator exposure to hazardous chemicals, improving workplace safety.
Overall, AB potting machines offer a range of advantages for businesses looking to improve the accuracy, efficiency, and reliability of their production processes.
performance;
High precision Panasonic PLC ensure high stably performance and precisely AB glue output quantity
High speed mixing motor, mixing glue well. According to glue features, static mixing is available
With defoaming function and mixing motor, no bubbles in glue, pre-heating is available for selection
Both AB tank with high level and low level liquid sensor, when the glue is not enough or the machine is abnormal, the machine will show the warning message. Humanized engineering design, avoid the serious damages. There's a professional sealing ring to make sure the glue tank in vacuum status. To avoid the glue to be crystallization or curved.
vacuum tank with auto glue filling function
* Inquiry and consulting support.
* Sample testing support.
* View our Factory.
* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.
Packaging | ||
Size | 150CM(L) * 110CM (W) * 170CM (D) | |
Weight | 550KGS | |
Packaging Details | The normal package is wooden box(Size: L*W*H). The wooden box will be fumigated. We will use pe film for packing or pack it according to customers special request. | |
Small automatic Glue dispensing machine with working area: L480mm*W480mm*H80mm
Glue dispenser for Round products with 3 heads
One component glue dispensing machine with working area: L700mm*W700mm*H80mm
Automatic glue mixing machine, manual glue dispenser
automatic Glue dispensing machine with working area: L1200mm*W1200mm*H80mm
Automatic glue mixing machine, manual glue dispenser, with long pipe
|
|
